| Model | LOG 320S8 | |||
|---|---|---|---|---|
| International Recognition Number | 1870/320 | |||
Injection System | Unit | A | B | C |
| Theoretical Injection Volume | cm3 | 1062 | 1231 | 1414 |
| Shot Weight | g | 966 | 1120 | 1286 |
| oz | 33.7 | 39.2 | 44.9 | |
| Injection Rate | mm/s | 170 | 210 | 240 |
| Injection Pressure | MPa | 207 | 178 | 155 |
| Injection Speed | g/s | 313 | 362 | 416 |
| Screw Diameter | mm | 65 | 70 | 75 |
| Aspect L/D Ratio | 22.6:1 | 21:1 | 19.6:1 | |
| Screw Stroke | mm | 320 | ||
| Screw Speed | rpm | 0-150 | ||
Clamping Unit |
||||
| Clamping Force | kN | 3200 | ||
| Opening Stroke | mm | 615 | ||
| Platen Size | mm x mm | 1000 x 945 | ||
| Space between Tie Bars | mm x mm | 710 x 655 | ||
| Mold Thickness (Min - Max) | mm | 280-770 | ||
| Template Maximum Stroke | mm | 1385 | ||
| Hydraulic Ejection Force | kN | 77 | ||
| Hydraulic Ejection Stroke | mm | 160 | ||
Power / Heating Unit |
||||
| Oil Tank Capacity | L | 500 | ||
| Hydraulic System Pressure | MPa | 17.5 | ||
| Pump Motor | kW | 39 | ||
| Heating Power | kW | 27 | ||
| Number of Heating Control Zones | 5+nozzle | |||
Other Machine Information |
||||
| Dry Cycle Time | sec | 5.0 | ||
| Machine Dimensions | m x m x m | 6.8 x 1.63 x 2.25 | ||
| Machine Weight | kg | 11300 | ||
| Model | LOG-320 | ||
|---|---|---|---|
| International Recognition Number | 1870/320 | ||
| Injection System | A | B | C |
| Theoretical Volume | 1062 | 1231 | 1414 |
| Actual Injection Volume | 966 | 1120 | 1286 |
| 33.7 | 39.2 | 44.9 | |
| Injection Speed | 313 | 362 | 416 |
| Injection Rate | 170 | 210 | 240 |
| Screw Diameter | 65 | 70 | 75 |
| Injection Pressure | 207 | 178 | 155 |
| Aspect Ratio | 22.6:1 | 21:1 | 19.6:1 |
| Screw Stroke | 320 | ||
| Screw Speed | 0-150 | ||
| Clamping System | |||
| Clamping Force | 3200 | ||
| Mold Opening Stroke | 615 | ||
| Template Size | 945 x 945 | ||
| Connecting Rod Inner Distance | 710 x 655 | ||
| Bulk Modulus | 280-770 | ||
| Template Maximum Stroke | 1385 | ||
| Hydraulic Ejection Stroke | 160 | ||
| Hydraulic Ejection Force | 77 | ||
| Power / Electric Heat | |||
| Hydraulic System Pressure | 17.5 | ||
| Oil Pump Motor | 39 | ||
| Electric Heat | 25.3 | ||
| Number of Heating Control Zones | 5* nozzle | ||
| Other | |||
| Cycle Time | 5.0 | ||
| Fuel Tank Capacity | 500 | ||
| Mechanical Dimensions | 6.8 x 1.63 x 2.25 | ||
| Theoretical Machine Weight | 12500 | ||
Technical Advantages
With LOG Machine technology, plastic products can be produced that set new standards in terms of surface finish and functional integration.
Flexible, energy-efficient injection molding machines for all types of parts will provide you with huge cost benefits.
Maximum ability to provide solutions with the latest technology and competent partners
Complete production solutions from small parts to large equipment.
Extremely short cycle times and stable processes for very large batches
Injection molding machines for individual products with high-quality, durable components
